FEATURES UL fire ratings up to 2 hours For use in insulated ceilings and non-insulated ceilings. Airtight (Per ASTM-E283) Quick connect provided 13-5/8" to 25" Bar hangers with captive nails and alignment foot Housing adjusts from 1-1/2" to accommodate various ceiling thickness For use only with UL or cUL Classified LED Retrofit kit suitable for 6 inches recessed housing. PLASTER FRAME Galvanized steel construction. The housing can be removed from plaster frame to provide access to the junction box. HOUSING Die formed 22 guage galvanized steel construction. Housing interior is comprised of a flexible non-combustible insulation. JUNCTION BOX Listed for through branch circuit wiring. Contains one 1-1/8", one 1/2", three 7/8" knockouts and four Romex pryouts with strain relief. BAR HANGER Pre-installed Real nail easily installs in regular lumber, engineered lumber. Bar Hangers are adjustable from 13-5/8" to 25" and can be repositioned 90 degree on plaster frame. Swivel bar hanger which is bendable at 90 degree angle will help to install more easily. APPLICATIONS Condominiums Apartment Buildings Multi-Family Commercial and Residential LISTINGS cULus Listed for Damp Location cULus Listed for Wet Location (with specified trims) cULus Listed for Feed Through Certified under ASTM-E283 for Air tight construction
