Product Description Diesel Injector Tester 60MPa This diesel injector tester is used to adjust the injector opening pressure, a seat nozzle oppression, and performs leak tests, spraying atomization repetition modeling tests and characteristic testing of gossip. This diesel injector tester comes with a heavy 0 to 600 BAR / 0 to 8700 PSI dual scale gauge, which helps stabilize vibrations in the needle, providing more accuracy in results and increase the life of the gauge. Excellent Manometer Test- In basic design with 0-60M Pa (0-600 bar/ 0-8700 psi) pressure gauge and 0.75L fuel measuring cup with a 5-micron original Bosch filter help to test the opening pressure of the injector and the valve accurately. Durable Aluminum Body- The fuel injection nozzle tester is made of selected high-quality materials to ensure a long-last use. It has a sturdy aluminum body, stainless pressure gauge and a plastic transparent oil cup. Multifunctional Tests- This fuel injector tester is the special equipment for inspecting fuel injectors. It can verify various mechanical tests of fuel injectors, such as opening pressure test, leakage test, atomization, and chattering test. With diversity function, and simple operation. Application- Widely used in the calibration of fuel injectors of diesel engines of automobiles and tractors. It is suitable for all types of diesel injectors except (CRDI) Common Rail Diesel Injectors. Specifications : Pressure range: 0-60MPa/0-600 bar/0-8700 psi Biggest test pressure: 60MPa Fuel tank capacity: 0.75L Pressure: 0-60Mpa Plunger Hole: 0.39''/10mm Nozzle connector: M14X1.5-M14X1.5, M14X1.5-M12X1.25, M14X1.5-M12X1.5 Outline dimension: 5.1x9x16.7 in / 13x23x42.5cm Gross weigth: 4.5KG Package Content: 1 X Diesel Injector Nozzle Tester #productDescription { color: #333333; word-wrap: break-word; font-size: small; line-height: initial; margin: 0.5em 0px 0em 25px; } #productDescription_feature_div > h2.default { font-size: medium; margin: 0 0 0.25em; } #productDescription_feature_div > h2.books { color:#333 !important; font-size:21px !important; line-height: 1.3; padding-bottom: 4px; font-weight: normal; margin: 0px; } #productDescription_feature_div > h2.softlines { color:#333 !important; font-size:21px !important; line-height: 1.3; padding-bottom: 4px; font-weight: bold; margin: 0px; } #productDescription > p, #productDescription > div, #productDescription > table { margin: 0 0 1em 0; } #productDescription p { margin: 0em 0 1em 1em; } #productDescription h3 { font-weight: normal; color: #333333; font-size: 1.23em; clear: left; margin: 0.75em 0px 0.375em -15px; } #productDescription table { border-collapse: inherit !important; margin-bottom: 0; } #productDescription table img { max-width: inherit !important; } #productDescription table td { font-size: small; vertical-align: inherit !important; } #productDescription ul li { margin: 0 0 0 20px; } #productDescription ul li ul { list-style-type: disc !important; margin-left: 20px !important; } #productDescription ul ul li { list-style-type: disc !important; margin-left: 20px !important; } #productDescription > ul ul li { list-style-type: disc !important; } #productDescription ul li ul li { margin: 0 0 0 20px; } #productDescription .aplus p { margin: 0 0 1em 0; } #productDescription small { font-size: smaller; } #productDescription.prodDescWidth { max-width: 1000px } P.when('jQuery').execute(function($){ $("#productDescription table").each(function() { var width = $(this).attr('width'); if (width) width += 'px'; else width = 'auto'; $(this).css('width', width); var padding = $(this).attr('cellpadding'); if (padding) padding += 'px'; else padding = '0px'; $(this).css('padding', padding); }); }); #productDescription h3 { margin: 0.75em 0px 0.375em -1px; }
